LDF Machinery Pvt. Ltd.
CHARACTERSTIC AND PARAMETERS
- The machine uses the dream dry cleaning solvent Green-Sol;
- At full load, each cycle takes 45-50 minutes;
- Equipped with drying recovery auxiliary heat technology, drying is more energy-saving;
- An efficient solvent management system without distillation saves electricity, water, labor and time for distillation;
- R&D of new filtration system, solvent purification in one step;
- Introduce the filter material compounding technology to complete the filtration and drying at the same time;
- Low-cost and simple filter maintenance;8. Filter residual extraction system, no waste of solvent;
- If equipped with air cooling system, no water is required for drying (no water system);
- The PLC touch screen is highly intelligent human-computer dialogue, and the all-Chinese interface is one-button operation, which is easy to learn.
| Model | MX-08A | MX-12A |
|---|---|---|
| Rated capacity (Kg) | 8 | 12 |
| Roller capacity (L) | 145 | 215 |
| Washing speed (rpm) | 20~50 | 20~50 |
| Drying speed (rpm) | 500~600 | 500~600 |
| Voltage (V) | 220/380 | 380 |
| Rated power (KW) | 9.7 | 12.7 |
| Compressed air pressure (MPa) | 0.4~0.6 | 0.4~0.6 |
| Cooling water pressure (Mpa) | 0.2~0.4 | 0.2~0.4 |
| Overall dimension (mm) | 1650×1250×1900 | 1650×1350×2000 |
| Weight (Kg) | 850 | 950 |
