LDF Machinery Pvt. Ltd.

CHARACTERSTIC AND PARAMETERS
- Horizontal installation of washing room and washing dewatering bucket, anti-corrosion; The inner liner is made of high-quality stainless steel material welded together. Key components are sourced from imported or domestic high-quality brands.
- Adopting a fully suspended shock-absorbing structure and variable frequency drive, the acceleration is smooth and effectively resolves the vibration of the machine. During dehydration, the amplitude is small, the dehydration force is large, and the moisture content of the clothes after dehydration is better than the national standard, without the need for a foundation.
- The frequency converter adopts an Easy Energy frequency converter, which can set the speed arbitrarily according to actual needs.
- Easy to operate, fully automatic computer control system, Chinese large screen LCD display, clear washing process at a glance, and free selection of washing program.
- Steam heating and electric heating can be used as options, and rear drainage can be used, which can be led to the trench with a hose to maintain indoor cleanliness.
- The feeding box uses hot water flushing to solve the problems of laundry detergent being difficult to dissolve in cold water and prone to scaling.
- Dehydration safety control function.
- High and low water level automatic control system, fully computer-controlled program, with 4 manual water level settings to choose from, and automatic water temperature control to choose from.
- The safety door lock and control linkage device have protective functions (can refuse misoperation such as opening the door when the equipment is running).
- The body and base are welded together, and all internal and external structures of the machine are coated with epoxy resin paint with strong corrosion resistance. The external panels of the body are made of stainless steel plates.
Model | XGQ-16N | Motor power (KW) | 2.2 |
Rated capacity (Kg) | 16~17 | Inverter (KW) | 2.2 |
Transfer cage volume (Lt) | 163 | Drainage valve (mm) | Φ50 |
Cage size (mm) | Φ730×390 | Hot water pipe (mm) | DN20 |
Washing speed (r/min) | 40 | Cold water pipe (mm) | DN20 |
Uniformly distributed speed (r/min) | 72 | Steam pipe | DN15 |
Clothing door diameter (mm) | 420 | Dimensions (mm) | Height 1550 |
Mid cycle (r/min) | 400 | Depth 980 | |
High viscosity (r/min) | 860 | Width 980 | |
Electric heating power (KW) | 7.5 | Whole machine weight (Kg) | 630 |
Model | XGQ-22N | Motor power (KW) | 3 |
Rated capacity (Kg) | 22~23 | Inverter (KW) | 3.7 |
Transfer cage volume (Lt) | 226 | Drainage valve (mm) | Φ50 |
Cage size (mm) | Φ730×540 | Hot water pipe (mm) | DN20 |
Washing speed (r/min) | 37 | Cold water pipe (mm) | DN20 |
Uniformly distributed speed (r/min) | 72 | Steam pipe | DN20 |
Clothing door diameter (mm) | 420 | Dimensions (mm) | Height 1550 |
Mid cycle (r/min) | 400 | Depth 1150 | |
High viscosity (r/min) | 900 | Width 980 | |
Electric heating power (KW) | 7.5 | Whole machine weight (Kg) | 700 |
Model | XGQ-25N | Motor power (KW) | 3 |
Rated capacity (Kg) | 25 | Inverter (KW) | 3.7 |
Transfer cage volume (Lt) | 250 | Drainage valve (mm) | Φ50 |
Cage size (mm) | Φ700×650 | Hot water pipe (mm) | DN20 |
Washing speed (r/min) | 37 | Cold water pipe (mm) | DN20 |
Uniformly distributed speed (r/min) | 72 | Steam pipe | DN20 |
Clothing door diameter (mm) | 420 | Dimensions (mm) | Height 1610 |
Mid cycle (r/min) | 400 | Depth 1250 | |
High viscosity (r/min) | 800 | Width 1110 | |
Electric heating power (KW) | 7.5 | Whole machine weight (Kg) | 750 |
