CHARACTERSTIC AND PARAMETERS
- The inner drum adopts stainless steel structure, which is smooth, clean and does not damage the fabric; the outer drum is treated with anti-corrosion coating, ensuring good corrosion resistance.
- The storage door is made of stainless steel with a lightweight body, allowing easy and convenient opening and closing. It features impact-resistant and heat-resistant glass, enabling users to observe fabric washing conditions during operation.
- The washing drum is equipped with a suspension system featuring hydraulic and friction damping, which significantly reduces vibration during the dehydration process and effectively resolves long-standing issues with excessive vibration.
- The machine supports both washing and dehydration functions. With frequency conversion speed control, it reduces space usage, saves garment loading/unloading time, and enhances work efficiency.
- Compact in size and attractive in design, the machine features a robust and simple structure, easy operation, excellent washing performance, and convenient maintenance—making it an ideal choice for fabric care.
- Equipped with a microcomputer control system and LED liquid crystal display, offering user-friendly operation and high reliability.
- Supports multiple intelligent features: mid-cycle cloth addition, fault diagnostics, power-off memory, child lock, custom programming, quiet operation, high-temperature wash, self-cleaning drum, and mite removal.
Model | SXQ-15D | SXQ-15Z | SXQ-20D | SXQ-20Z | SXQ-25D | SXQ-25Z |
---|---|---|---|---|---|---|
Heating mode | Electricity | Vapour | Electricity | Vapour | Electricity | Vapour |
Washing capacity (kg) | 15 | 15 | 20 | 20 | 25 | 25 |
Drum diameter * depth (mm) | 600*500 | 600*500 | 700*500 | 700*500 | 800*500 | 800*500 |
Motor power (KW) | 0.75 | 0.75 | 1.5 | 1.5 | 3.5 | 3.5 |
Heating power/220V | 6 | / | 6 | / | 6 | / |
Heating power/380V | 9 | / | 9 | / | 18 | / |
Cold water pipe diameter (inch) | 1/2 | 1/2 | 3/4 | 3/4 | 3/4 | 3/4 |
Hot water pipe diameter (inch) | 1/2 | 1/2 | 3/4 | 3/4 | 6分 | 3/4 |
Steam inlet pipe diameter (inch) | / | 1/2 | / | 1/2 | / | 1/2 |
Compressed air pipe diameter (mm) | / | 8 | / | 8 | / | 8 |
Compressed air pressure (MPa) | / | 0.4~0.6 | / | 0.4~0.6 | / | 0.4~0.6 |
Drain pipe diameter (inch) | 2 | 2 | 2 | 2 | 2 | 2 |
Steam consumption (Kg/h) | 10 | 10 | 15 | 15 | 15 | 15 |
Voltage (V) | 220/380 | 220/380 | 220/380 | 220/380 | 220/380 | 220/380 |
Length * Width * Height (mm) | 800*975*1258 | 800*975*1258 | 900*1016*1305 | 900*1016*1305 | 980*1062*1425 | 980*1062*1425 |
Net weight (kg) | 350 | 350 | 370 | 370 | 610 | 610 |
