LDF Machinery Pvt. Ltd.
CHARACTERSTIC AND PARAMETERS
- 1. This type of dryer is controlled by microcomputer fully automatic fuzzy intelligent control. It can set a variety of temperature, time and positive and reverse programs according to the different drying cloth, which is more convenient to operate and allows the drying effect to be controlled at will.
- 2. The special anti-winding and anti-wrinkle design of the dryer makes the drying effect more ideal.
- 3. The stainless steel structure of the tank makes the machine durable.
- 4. The oversized clothing door is designed to make it more convenient to put and take clothes.
- 5. Anti-dust fan, fast and efficient, fully saving energy and low noise.
- 6. The transmission system adopts multi-level V-belt transmission and special narrow V-belt transmission, with strong transmission capacity, good wear resistance, high stability and convenient daily maintenance.
- 7. The upper part of the dryer is equipped with a large heat exchanger, which has large heating area, more sufficient heat, fast temperature rise and short drying time.
- 8. The panel is plastic spray panel, with stainless steel structure inside. The machine is beautiful, environmentally friendly and durable.
- 9. Thin multi-function computer board, not protruding, beautiful appearance, easy operation.
- 10. Drawer-type plush collector, easy to use.
| Parameter Model | Unit | HG-20 (HGR-20) | HG-25 (HGR-25) | HG-30 (HGR-30) |
|---|---|---|---|---|
| Capacity | Kg | 20 | 25 | 35 |
| Drum Size | mm | φ750×670 | φ970×660 | φ960×840 |
| Motor Power | Kw | 0.12 | 0.75 | 1.1 |
| Fan Power | Kw | 0.55 | 0.75 | 1.1 |
| Heating Power | Kw | 9KW / 14KW | 24 | 27 |
| Steam Consumption | Kg/次 | 35 | 55 | 70 |
| Steam Pressure | MPa | 0.4~0.5 | 0.4~0.5 | 0.4~0.5 |
| Rated Voltage | V | 220 / 380 | 380 | 380 |
| Diameter of Air Outlet | mm | 100 | 185 | 185 |
| External Dimensions | mm | 830×1200×1570 | 1.08×1.36×1.92 | 1.06×1.44×1.92 |
| Whole Machine Weight | Kg | 380 | 400 | 450 |
