Drying Machine

HGN type New type small dryer

  • Home
  • HGN type New type small dryer
LDF Machinery Pvt. Ltd.

CHARACTERSTIC AND PARAMETERS

  • This type of dryer is controlled by microcomputer fully automatic fuzzy intelligent control. It can set a variety of temperature, time and positive and reverse programs according to the different drying cloth, which is more convenient to operate and allows the drying effect to be controlled at will.
  • The special anti-winding and anti-wrinkle design of the dryer makes the drying effect more ideal.
  • The stainless steel structure of the tank makes the machine durable.
  • The oversized clothing door is designed to make it more convenient to put and take clothes.
  • Anti-dust fan, fast and efficient, fully saving energy and low noise.
  • The transmission system adopts multi-level V-belt transmission and special narrow V-belt transmission, with strong transmission capacity, good wear resistance, high stability and convenient daily maintenance.
  • The upper part of the dryer is equipped with a large heat exchanger, which has large heating area, more sufficient heat, fast temperature rise and short drying time.
  • The panel and liner are made of stainless steel. The machine is beautiful, environmentally friendly and durable.
  • Thin multi-function computer board, not protruding, beautiful appearance, easy operation.
  • Drawer-type plush collector, easy to use.
Model Unit HGN-20 HGN-30
Capacity Kg 20 30Kg
Inner container size mm ø800*710 ø950*830
Main motor W 200 400
Fan motor W 550 550
Heating power KW 15 24
Total power KW 15.75 24.95
Supply voltage V 220/380 380
Air outlet mm ø160 ø160
Wiring m2 6~10 10
Belt model A1829*1 B1956*2
External dimensions mm 870*1210*1690 1050*1390*1740
Weight Kg 300 425
