CHARACTERSTIC AND PARAMETERS
- The feeding height of the towel folding machine can be adjusted to meet the needs of operators of different heights. The feeding platform has been extended to provide better adhesion for longer towels.
- Compared with similar devices, it has the fewest moving parts and all use standard parts, making it easy to replace the transmission belt and having better adjustability.
- Compared with similar devices, it has the fewest moving parts and all use standard parts, making it easy to replace the transmission belt and having better adjustability.
- It can automatically recognize and classify various types of linens based on their length, so there is no need for early sorting. For linens of the same length that require different folding methods, width classification can also be adjusted.
- The equipment is equipped with a stacker and conveyor, which automatically counts and delivers to the operator's workstation.
- The equipment is equipped with a stacker and conveyor, which automatically counts and delivers to the operator's workstation.
| Model | MJZDJ-2 | MJZDJ-4 |
|---|---|---|
| Maximum folding width (mm) | 1800*800 | 1800*800 |
| Folding quantity (fold) | 2 | 2+2 |
| Maximum folding speed (m/min) | 50 | 50 |
| Folding capacity (sheets/hour) | 1300 | 1300 |
| Voltage (V/Hz) | 380/50 | 380/50 |
| Total power (KW) | 0.76 | 2 |
| Air pressure (Mpa) | 0.4~0.6 | 0.4~0.6 |
| Weight (Kg) | 600 | 1200 |
| Dimensions (length * width * height) (mm) | 2400*1470*1715 | 4500*2150*1350 |
